Casambi 15W PRO Constant Current Smart Driver
Price on Request
Tax excluded. Shipping calculated at checkout
Casambi 15W PRO Constant Current Smart Driver
A compact Casambi-enabled constant-current LED driver designed for professional dimming applications. Available in 1-channel and 2-channel versions, with selectable output current for flexible matching with compatible LED luminaires.
Key Features
- Casambi wireless lighting control
- 15W constant-current LED driver
- Available in 1-channel and 2-channel versions
- Selectable output current: 200mA, 250mA, 300mA or 350mA
- Output voltage: 20–42VDC
- Deep dimming down to 0.1%
- Power factor >0.98 at 230VAC
- Surge immunity >4kV
- Compact professional driver format
Technical Specifications
| Output Power | 15W |
| Input Voltage | 180–270VAC, 50Hz |
| Output Voltage | 20–42VDC |
| Selectable Output Current | 200 / 250 / 300 / 350mA |
| Current Selection | DIP switch |
| Dimming Range | 0.1%–100% |
| Power Factor | >0.98 @ 230VAC |
| Surge Immunity | >4kV |
| Operating Temperature | 5°C to 45°C |
| Dimensions | 146 × 36 × 25 mm |
| Wireless Platform | Casambi |
| Wireless Range | 15 m line-of-sight |
Available Versions:
- 1 Channel — CCD-15-350-1-PRO-CSB
- 2 Channel — CCD-15-350-2-PRO-CSB
