D1 Multifunction Rotary Casambi Switch
Price on Request
Tax excluded. Shipping calculated at checkout
D1 Multifunction Rotary Casambi Switch
The D1 Multifunction Rotary Switch is a wall-mounted Casambi control interface combining a rotary knob with configurable push buttons. The knob can be used for intuitive lighting control including brightness and, where supported by the bound lighting, colour-temperature adjustment. Its preset buttons can be configured through the Casambi App for direct access to luminaires, groups, scenes and animations.
Key Features
- Rotary knob for smooth dimming
- Colour-temperature adjustment for compatible bound lighting
- Configurable preset buttons through the Casambi App
- Individual luminaire, group and all-luminaires control
- Scene and animation recall
- Bluetooth Casambi network control
- Designed as a multi-function control panel for lighting and linked scene control
Technical Specifications
| Product Size | 86 × 86 × 25.4 mm (knob 16 mm) |
| Bottom Shell Depth | 28 mm |
| Package Size | 100 × 100 × 75 mm |
| Weight | 0.173 kg |
| Gross Weight | 0.298 kg |
| Installation | 86 mounting box, depth > 50 mm |
| Input Voltage | 110-240VAC, 50/60Hz |
| Network Mode | Bluetooth Casambi |
| Finish / Glass | Phantom Gray, Starlight Gold & Mica White: AG Glass Lava White & Lava Gray: Art Glass |
| Fire Rating | 94-V0 |
| Working Temperature | -10°C to +60°C |
| Working Humidity | ≤95% RH, non-condensing |
Price: Price on Request
