GRID-36W

GRID SERIES

Architectural Recessed & Surface Linear Spotlights

The GRID series redefines modern architectural lighting with its modular linear design and precise beam control. These low-glare luminaires are ideal for high-utility commercial and hospitality applications where form meets function. Available in multiple wattages, beam angles, and installation formats (recessed, surface), the GRID range allows unmatched flexibility across projects of any scale.

Product Variants & Technical Specifications:

🔸 GRID 36W / 50W

• Dimensions:

  • 36W: 300 × 54 × 66 mm

  • 50W: 380 × 54 × 66 mm

• Cutout:

  • 36W: 295 × 50 mm

  • 50W: 375 × 50 mm

• Body Color: WH | BK

• Beam Angle: 24°, 36°

• CRI: 90+

• CCT Options: 2700K / 3000K / 3500K / 4000K

• Driver Options: Philips, Osram, Fulham, True, CCT-RF, CCT-Switch, Bluetooth, DALI

• Lumen Output:

  • 36W: 3600–4200 lm

  • 50W: 5000–5600 lm
